CP8609 eBlueTork - Battery Powered Wheel Torque Wrench (900 Nm)
Revolutionizing Heavy Vehicle Safety and Fleet Maintenance
The CP8609 eBlueTork is a dedicated 1" battery-powered torque wrench specifically engineered for the heavy truck and bus industry. Delivering a precise torque range of 250 to 900 Nm (185–665 ft.lb), this tool is designed to master the unique challenges of wheel bolting. As a specialized model in our Battery Powered Torque Wrenches lineup, it provides the "Right Torque" to guarantee passenger safety and prevent "wheel-off" incidents.
By combining a sturdy, dedicated gearbox with the CPLinQ digital interface, the CP8609 ensures real-time torque service records for every vehicle in the workshop. It replaces manual torque wrenches and high-vibration impact tools with a single-operator solution that is lightweight, accurate, and completely cordless.
Key Benefits
Technical Specifications
| Feature | Imperial | Metric |
|---|---|---|
| Max Torque | 665 ft.lb | 900 Nm |
| Min Torque | 185 ft.lb | 250 Nm |
| Recommended Torque | 530 ft.lb | 720 Nm |
| Accuracy | ±4% | ±4% |
| Output Drive Size | 1" Square | 1" Square |
| Main Material Type | Steel | Steel |
| Weight (Tool & Battery Only) | 9.26 lb | 4.2 kg |
| Weight (With S-Type Arm) | 10.7 lb | 4.86 kg |
| Free Speed | 15 rpm | 15 rpm |
| Battery Type | 36V / 2.5Ah Li-ion | 36V / 2.5Ah Li-ion |
| Safety Start System | Double-trigger | Double-trigger |
| Connectivity | CPLinQ App (CQ & TC versions) | CPLinQ App (CQ & TC versions) |
| Tightening Modes | Torque, Angle, & Check* | Torque, Angle, & Check* |
| Length (L) | 13.4 in | 341 mm |
| Height (H) | 11.2 in | 285 mm |
| Width (W) | 3.0 in | 77 mm |
CP8609 Configuration Options
The eBlueTork series is available in multiple configurations to suit specific wheel types and reporting requirements.
| Model Series | Connectivity | Features |
|---|---|---|
| Standalone (B) | None | Simple trigger operation for standalone performance. |
| Connected (C) | CPLinQ | Digital control and maintenance tracking. |
| Connected Quality (CQ) | CPLinQ | Full data collection, counting sequences, and reporting. |
| Torque Check (TC) | CPLinQ | Advanced checking of nut loosening and residual torque. |
CP8609 eBlueTork Model Reference & Part Numbers
The CP8609 is available in various software levels and hardware configurations. Select the model that matches your required trigger system and reaction bar type.
| Version | Trigger Type | Reaction: Blade | Reaction: Cup | Reaction: Ext. Cup |
|---|---|---|---|---|
| Standalone | Trigger + Safety Button | CP8609-B (6151570500) | CP8609-C (6151570730) | CP8609-xC (6151570780) |
| Standalone | 1 Trigger | CP8609-BT (6151570440) | CP8609-CT (6151570560) | CP8609-xCT (6151570620) |
| Connected | Trigger + Safety Button | CP8609C-B (6151570510) | CP8609C-C (6151570740) | CP8609C-xC (6151570790) |
| Connected | 1 Trigger | CP8609C-BT (6151570450) | CP8609C-CT (6151570570) | CP8609C-xCT (6151570630) |
| Connected Quality | Trigger + Safety Button | CP8609CQ-B (6151570520) | CP8609CQ-C (6151570750) | CP8609CQ-xC (6151570800) |
| Connected Quality | 1 Trigger | CP8609CQ-BT (6151570460) | CP8609CQ-CT (6151570580) | CP8609CQ-xCT (6151570640) |
| Torque Check | Trigger + Safety Button | CP8609TC-B (6151570530) | CP8609TC-C (6151570760) | CP8609TC-xC (6151570810) |
| Torque Check | 1 Trigger | CP8609TC-BT (6151570470) | CP8609TC-CT (6151570590) | CP8609TC-xCT (6151570650) |
Key Technical Breakdown
- Trigger + Safety Button: This dual-start system ensures operator safety by requiring both hands for operation, preventing accidental starts.
- 1 Trigger (-T suffix): A single-trigger model for applications where higher mobility and single-handed starting are prioritized.
- Accuracy (6 sigma): All models maintain a high precision of ±4%.
- Torque Range: Delivers a constant range of 250-900 Nm (185–665 ft.lbs) regardless of version.
- Battery Performance: Optimized for heavy-duty use with approximately 250 cycles per charge.
Design & Functional Excellence
Intuitive OLED Display
High-resolution interface provides clear overview of torque settings and tool status, even in low-light workshop environments.
Advanced Safety
Features a second start button and automatic reaction arm release to protect technicians from injury.
Extended Operation
Powered by a compact 36V/2.5Ah Li-ion battery, allowing for up to 250 cycles on a single charge.
CP Care Protection
Enhance your investment with a preventive maintenance contract, potentially extending tool life by up to 20% while optimizing your maintenance budget.
The CP8609 eBlueTork is more than a tool; it is a commitment to quality control and passenger safety in the heavy transport sector.
Contact TorqLite today to discover how our professional Torque Multipliers can revolutionize your fleet's safety and workshop productivity.
